EcoFlow Smart Gateway (200A)
$2,199.00

EcoFlow Smart Gateway (200A)

In Stock SKU: EFATS-US
$2,199.00
EcoFlow Smart Gateway (200A)
Regular Discount
Plan Discount
Subtotal
You Saved Today
Short Description
Have questions? Expert help just one click away Contact Us

Product Description

The Smart Gateway is the simpler road to whole-home backup. It sits between the grid and an existing backup subpanel, hands it up to 200 A across six circuits, and switches to battery automatically when the power fails — without the wholesale panel replacement that a Smart Home Panel 3 install involves.

What's in the box

  • EcoFlow Smart Gateway, 200A ×1
  • EcoFlow Smart Inlet Box ×1
  • Smart Inlet Box connection cable, SP6 to SP6 ×1
  • Mark-off template ×1
  • Warranty card ×1
Not included — sold separately
  • DELTA Pro Ultra inverter and batteries
  • Backup subpanel
  • Electrician labour and permits

The Gateway handles switching and metering only — the stored energy comes from a DELTA Pro Ultra system, and installation is licensed-electrician work.

Not sure what else you need? Call the Satmodo team on (619) 238-0205 and we will check it against your setup.

Specifications

Rated input120/240 V and 120/208 V, 60 Hz
Branch circuitsSix outputs rated 60 A each
Maximum backup panel output200 A
EnclosureNEMA 3R, rated for outdoor installation
Overvoltage categoryIV
Operating temperature−22 °F to 122 °F (−30 °C to 50 °C)
Metering accuracy0.5% on the main circuit, 1% per branch
ConnectivityBluetooth, Wi-Fi, Ethernet, CAN and RS485
CertificationUL 67, UL 869A, UL 916, UL 1741
Weight65.5 lb (29.7 kg)
Dimensions15.2 × 7.4 × 35.6 in (385 × 188 × 905 mm)
Warranty10 years

Specifications from EcoFlow's published product data for the Smart Gateway (200 A).

Gateway or Smart Home Panel 3?

Choose the Gateway when you already have, or are happy to add, a backup subpanel and want the switching handled cleanly with less disruption to your existing service. Choose the Smart Home Panel 3 when you want every circuit in the house individually metered and controllable from the app, and are willing to take on the larger install. Both are 120/240 V and both need a DELTA Pro Ultra behind them.

What you can expect during an outage

The transfer is automatic — no going outside to throw a switch, no starting anything. Per-circuit metering at 1% accuracy means you can watch where your stored energy is going from your phone and shed the loads that are not worth it, which is usually what decides whether a battery lasts one day or three.

Installation

This is licensed-electrician work that ties into your service entrance and is permitted in most jurisdictions. The NEMA 3R enclosure is designed for an exterior wall beside the existing meter. If you want help sizing the system before you book an electrician, call us on (619) 238-0205.

Where people use it

Automatic switching for a backup subpanel — Home backup
Home backup Automatic switching for a backup subpanel
Ready before the next outage — Storm preparedness
Storm preparedness Ready before the next outage

Common questions about the Smart Gateway

Scale. The Smart Gateway hands 200 A to an existing backup subpanel across six 60 A circuits; the Smart Home Panel 3 replaces that subpanel entirely with thirty-two individually metered and switched branches. The Gateway is the simpler, less invasive install; the Panel gives you far more control.

Yes — it works with the DELTA Pro Ultra and DELTA Pro Ultra X inverters, and with EcoFlow's PowerPulse EV charger. On its own it stores nothing.

Yes. It is a 120/240 V device, so well pumps, ranges and central air can be backed up, within whatever your inverter and battery capacity supports.

The enclosure is NEMA 3R and rated from −22 °F to 122 °F, so an exterior wall beside the existing service is a standard installation.

A licensed electrician. This ties into your service entrance, so it is permitted work in most jurisdictions — not a weekend project, whatever your comfort level with wiring.

Under 40 dB. Mounted outside, you will not hear it from inside the house — which is the point compared with a standby generator.
