Core 9523 Satellite Transceiver Module
In Stock
SKU:
CORE-9523-SAT-TRAN-MOD
$949.00
was
Have questions?
Expert help just one click away
Contact Us
Product Description
The Iridium Core 9523 brings simplified worldwide voice and data accessibility, in the smallest, lightest, and most technologically advanced satellite transceiver ever built. It’s an incredible 90% smaller than its predecessor and features standardized connectors so that it can easily integrate into new products developed by Iridium partners allowing penetration into under-served markets.
| SPECIFICATIONS | |
| Pole-to-pole global coverage | |
| Ultra compact form factor | |
| Single-board transceiver | |
| Standardized connectors | |
| Voice, Circuit Switched Data and RUDICS | |
| Short Burst Data (SBD) capable | |
| Direct PCB integration | |
| FCC, Industry Canada, and CE approval* | |
| * For applications using an antenna with a gain of up to 3dbi. | |
| Capabilities | |
| Iridium Voice, SMS, Circuit Switched Data and RUDICS | |
| Maximum mobile originated SBD message size 1960 | |
| Maximum mobile terminated SBD message size 1890 | |
| Mechanical | |
| Length 70.44 mm | |
| Width 36.04 mm | |
| Height 14.6 mm (reservoir capacitors) 8.9 mm (screen can) | |
| Weight 32g | |
| Environmental | |
| Operating Temp. -30ºC to + 70ºC | |
| Operating Humidity ≤ 75% RH | |
| Storage Temp. -40ºC to + 85ºC | |
| Storage Humidity ≤ 93 % RH | |
| RF Parameters | |
| Frequency Range 1616 MHz to 1626.5 MHz | |
| Duplexing Method TDD (Time Domain Duplex) | |
| Input/Output Impedance 50 Ω | |
| Multiplexing Method TDMA/FDMA | |
| DC Power Input | |
| VBAT Power Input Specifications | |
| Nominal Voltage +3.7 V | |
| Voltage Limits +3.2 V to +6 V | |
| Maximal Current 500 mA | |
| VBAT Typical Current at Nominal +3.7 V | |
| Standby Current 70 mA | |
| Peak Current during Call 300 mA | |
| Average Current during Call 110 mA | |
| VBOOST Power Input | |
| Nominal Voltage +27 V | |
| Absolute Maximal Voltage +35 V | |
| Maximal Recommended Voltage +32 V | |
| Minimal Voltage during Call Transmit Burst +10.5 V | |
| Maximal Current 1 A | |
| VBOOST Power Consumption | |
| Typical Average Power during Call 2.3 W | |
| Maximal Average Power during Call 3.1 W |
Can I buy a satellite phone?
Yes you can buy satellite phones, we offer the best satellite communication options. Including Iridium, Globalstar, and Inmarsat. Satmodo offers satellite phones that work anywhere in the world.
Do I need to rent or purchase a satellite phone?
If you are needing a satellite phone more than 6 weeks out of a year we always suggest purchasing. This will save you money in the long run. If you are just doing a short camping, hiking and hunting, etc. We recommend renting the satellite phone.
Why do people need satellite phones?
If you are planning on going on a trip where cell service is not available or if you want to be prepared for the next natural disaster. Satellite phones work when nothing else does. If there is no power and no cell service your satellite phone will work. Making this the most reliable form of communication.
How quickly can I get a satellite phone?
Satmodo can get you a satellite phone or satellite internet SAME DAY! We do always recommend planning ahead of time to save money on shipping costs. However, we can get you your devices same day if need be.
Which satellite phone has the best coverage?
Satmodo only works with the best networks. Iridium, Globalstar, and Inmarsat all offer different coverage areas. The only network that has global coverage is the Iridium Network.
More Information
| Airtime Group | Iridium Short Burst Data Airtime 2 |
|---|---|
| SKU | CORE-9523-SAT-TRAN-MOD |
| Use physical product data | No |
| Item Returns | This item can be returned |
