Product Description
SAILOR 6110 mini-C GMDSS System
The SAILOR 6110 mini-C will become an integral part of your vessel’s communication system, rather than simply satisfy mandatory GMDSS requirements. This solution will reliably handle all GMDSS, SSAS, & LRIT operations in one place.
A World First
The SAILOR 6006 Message Terminal, the industry first touch screen, Wheelmark certified GMDSS terminal, guides the operation of the SAILOR 6110 mini-C. The messaging terminal provides an intuitive user experience, providing access to its functions through a multimedia-style interface, that maintains safe operation of the vessel’s IMO safety and tracking systems.
Cabling Innovations
A major innovation for the SAILOR 6110 mini-C is the reduced time and cost required for installation and routine maintenance. A unique style of cabling, CAN-BUS (NMEA 2000), makes it much easier to procure cables, at custom lengths, with the right connectors, for optimized cable routing. Even better, your alarm panels and other subsystems are all connected with RJ45 cables through a switch, so expanding your system is simple and affordable.
SAILOR 6110 mini-C GMDSS System Components
- SAILOR 3027C mini-C GMDSS Terminal
- SAILOR 6006 Message Terminal
- SAILOR 6194 Terminal Control Unit (TCU) – optional
- SAILOR 6101 Alarm Panel
- SAILOR 6103 Alarm Panel
- SAILOR 6197 Ethernet Switch
| GENERAL SPECIFICATIONS |
| Absolute power supply range |
9 – 32 VDC |
| Nominal power input |
15 VDC |
| Power consumption (typical) |
Rx: 1.85 W @ 15 VDC |
| Tx: 22 W @ 15 VDC |
| GPS module |
50 channel (Galileo ready) |
| Transceiver interface |
NMEA 2000 DeviceNet Mini-style, Male |
| I/O interface |
CAN-BUS (NMEA 2000) |
| Dimensions |
Diameter: 170.5 mm |
| Height: 145 mm (without pole mount) |
| Weight |
1.10 kg (without pole mount) |
| TERMINAL UNIT SPECIFICATIONS |
| General specifications |
Inmarsat C GMDSS Type Approved |
| Wheelmark Approved |
| 3027C mini-C Transceiver |
| ANTENNA UNIT SPECIFICATIONS |
| G/T |
-23.7 dBk at 5° elevation |
| EIRP |
Min. 7 dBW at 5° elevation |
| Antenna elevation |
-15° to 90° |
| Operating frequencies |
Rx Frequency Band: Rx: 1525 – 1545 MHz |
| Tx Frequency Band: Tx: 1626.5 – 1646.5 MHz |
What is ThraneLINK?
ThraneLINK creates a new opportunity for vessels using SAILOR products. This sophisticated communication protocol networks all of your SAILOR gear so you can access it from a single point and interact to perform remote diagnostics. This optimizes your maintenance and keeps your ownership costs low. You will need less time to troubleshoot problems and service issues and installation of new equipment is made even easier because your ThraneLINK will automatically recognize when a new product is added to your system.
